Download and Install TWRP on Pixel 4 XL


A working build of TWRP for Pixel 4 XL is now available to download. This is a step-by-step guide that explains how to install TWRP on Pixel 4 XL.

This Pixel 4 XL TWRP is brought to you by developer bigbiff.

TWRP Pixel 4 XL

DONATION TO DEVELOPER(S) AND TWRP PROJECT:

If you like the work the developer(s) then do consider for a contribution to bigbiff and TWRP project:
Donate to bigbiff
Donate to dees_troy TWRP’s Lead developer

[su_note note_color=”#F9D9D9″ text_color=”#AA4343″ radius=”3″ class=”” id=””]DISCLAIMER:
Installing TWRP recovery on Pixel 4 XL requires an unlock bootloader, which may void the warranty and delete all data on your phone. Make sure you back up important data.

You are the only person making changes to your phone and I cannot be held responsible for the mistakes done by you. So, flash at your own risk![/su_note]

About this TWRP for Pixel 4 XL

– TWRP version: 3.4.0-0
– Device Codename: Coral
– Supported Android Version: Android 10

[su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]Currently Supports Android 10 but soon you will get to see the Android 11 support when the stable API releases.[/su_note] – Build date:  6th June 2020

What’s Not Working?

[su_note note_color=”#F9D9D9″ text_color=”#AA4343″ radius=”3″ class=”” id=””]This recovery image is the test build so sideload and repacking TWRP recovery are not working but soon we will update the file with working ADB sideload and repacking feature.[/su_note]

Where to download TWRP for Pixel 4 XL?

[su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]Below is a list of files or guides required to install or flash TWRP recovery on Pixel 4 XL. The next section has a step by step guide that explains when and how to use these files or guides in the process.[/su_note] [su_note note_color=”#D8F1C6″ text_color=”#769958″ radius=”3″ class=”” id=””] [/su_note]

How to Install TWRP on Pixel 4 XL?

Installing TWRP on the phone requires an unlock bootloader. So, I have divided this whole guide into two parts as below:

  1. Bootloader Unlock
  2. Flashing the TWRP

Unlocking the Bootloader

[su_note note_color=”#D8F1C6″ text_color=”#769958″ radius=”3″ class=”” id=””]Visit this How To Unlock Bootloader Pixel 4 XL page to get a detailed step-by-step guide with screenshots.[/su_note]

Flashing or Booting the TWRP

  1. Download the TWRP recovery for Pixel 4 XL.
  2. Download and Install the ADB and Fastboot utilities.
  3. Then connect the phone to the PC using a USB cable.
    [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- On your phone, if you see such as “Allow USB debugging” then just tap on OK to proceed.[/su_note]
  4. On the computer, open a command prompt (on Windows) or terminal (on Linux or macOS) window, and execute the below command to restart your phone into fastboot mode or bootloader mode:
    adb reboot bootloader[su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- You can also enter into fastboot or bootloader mode by turning off the phone and then pressing the Power button + Volume Down button.[/su_note]
  5. As this is an A-only device, the TWRP needs to be flashed on the recovery partition. So, execute one of the following command as per the requirement:
    Execute below command to flash the TWRP permanently:
    fastboot flash recovery twrp-3.4.x-xx.img
    (or)
    Execute below command to boot the TWRP temporarily:
    fastboot boot recovery twrp-3.4.x-xx.img[su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]While executing this command make sure to replace the twrp-3.4.x-xx.img with the actual filename of the TWRP.[/su_note]
  6. Wait for the fastboot command to finish installing the TWRP on Pixel 4 XL.

That’s all on installing TWRP on Pixel 4 XL. For some reason, if it fails, you can login and reply below so that I can try to help you troubleshoot the issue.

After installing TWRP on Pixel 4 XL

You can do many things after installing TWRP on Pixel 4 XL. Below are few such examples:

  • You can enable Root on Pixel 4 XL
  • You can install one of the custom ROMs available for Pixel 4 XL
  • You can install some of the mods, magisk modules, etc.

Add-on links for Pixel 4 XL

Following are some extra resources for Pixel 4 XL which you may be interested in:
– LineageOS 17.1 for Pixel 4 XL
– GCam for Pixel 4 XL

Visit the following to get other updates of Pixel 4 XL (codename: Coral) on Android Custom ROMs, LineageOS ROMs, and all other device specific topics.
